Features:

Online double conversion

IGBT rectifier, high input power factor

Standard in-built output isolation transformer (300~600kVA)

Wide input voltage range

DC cold start function

Advanced battery charging management

Intelligent fan speed control

ECO mode and EPO function

Full protection function

Intelligent RS232/RS485 & dry contact communication function

Maintenance Bypass

SNMP adapter (optional)

Advanced no-master-slave parallel technology (optional)

Intelligent battery monitor system-MMBM (optional)

read more

Features:

Online double conversion

Fully DSP control

Advanced 3-level technology, high input power factor

IGBT rectifier

High reliability and performance

Wide input voltage range

DC cold start function

Advanced battery charging management

Frequency converter function (40-120kVA)

Small footprint design

Intelligent fan speed control

ECO mode and EPO function

Full protection function

Intelligent RS232 /RS485 Communication Port

Dry contact, maintenance Bypass

SNMP adapter (optional)

Advanced no-master-slave parallel technology (optional)

Intelligent battery monitor system – MMBM (optional)

read more

Features:

• Online double conversion
• High reliability DSP control
• Advanced PFC technology
• Wide input voltage range
• DC cold start function
• Intelligent fan speed control
• Full protection function
• Advanced battery charging management
• Intelligent RS232+USB+EPO communication port
• SNMP adapter or dry contact (optional)
• Advanced no-master-slave parallel technology (optional)
• 1P/1P or 3P/1P is suitable without additional settings (15kVA and 20kVA only)

Applications:

IT devices

Precision instruments

Data centre

Intelligent equipment

read more

Features:

Hot-swappable battery design

User-freiendly and easy-shift LCD display

Full digital control technology

Three level inverter technology

High AC/AC efficiency up to 93.5%

Low THDi: < 5%

High input power factor up to 0.996

High output power factor up to 1.0

Intelligent RS232+USB+EPO communication port

Perfect LCD display panel

Programmable rear panel

Full options for communication and monitoring

Selectable output sockets

SNMP or dry contact (optional)

External battery pack (optional)

Programmable power management outlet (optional)

read more

Features:

• Online double conversion
• Rack and tower convertible
• High input power factor
• Wide input voltage range
• Compact and light weight
• High reliability and performance
• Low THDi≤5%
• With ECO function
• Intelligent RS232+USB+EPO communication port
• Full protection function & Automatic bypass
• UPS management software (optional)
• SNMP or dry contact (optional)
• External battery bank, rack kits (optional)

Applications:

19″ rack device

Computer room

Data centre

Point-of-sale

Router

Hub and network device

Commercial facility

Precision instrument

read more

Features:

• Full digital control technology
• Three level inverter technology
• High AC/AC efficiency up to 94%
• Low THDi: < 5%
• High input power factor up to 0.996
• High output power factor up to 1.0
• Intelligent RS232+USB+EPO communication port
• ECO function
• Perfect LCD display panel
• Programmable rear panel
• Full options for communication and monitoring
• SNMP or dry contact (optional)
• External battery bank, Rack kits (optional)

Applications:

19’’ rack device

Computer room

Data centre

Point-of-sale

Router

Hub and network device

Commercial facility

Precision instrument

read more

Features:

• Isolation output transformer
• Online double conversion
• High input power factor
• Wide input voltage range
• Full protection function
• Automatic bypass
• High reliability and performance
• THDi≤5%
• Dual Output 208V/120V voltage
• Intelligent RS232 communication port
• EPO function
• UPS management software (optional)
• SNMP or USB or dry contact (optional)
• Manual bypass switch (optional)
• External Battery Bank (optional)

Applications:

Data centre

Point-of-sale

Router

Hub and other network device

Commercial facility

Precision instrument

read more

Features:

• Online double conversion
• High input power factor
• Wide input voltage range
• Full protection function
• Automatic bypass
• High reliability and performance
• Low THDi≤5%
• With ECO function
• Intelligent RS232+USB+EPO communication port
• UPS management software (optional)
• SNMP or dry contact (optional)
• External battery bank (optional)

Applications:

• Data centre
• Point-of-sale
• Router
• Hub and other network device
• Commercial facility
• Precision instrument

Part No.	Description
77-1047- U	CN-TX11 Series, Online transformer less double conversion UPS (single Phase In – single phase out), 6kVA/4.8kW, 0.8pf, 192Vdc, 1A charger with 16 x 12V, 7Ah batteries
77-1048-U	CN-TX11 Series, Online transformer less double conversion UPS (single Phase In – single phase out), 6kVA/4.8kW, 0.8pf, 192Vdc, 6A charger without batteries
77-1049-U	CN-TX11 Series, Online transformer less double conversion UPS (single Phase In – single phase out), 10kVA/8kW, 0.8pf, 192Vdc, 1A charger with 16 x 12V, 7Ah batteries
77-1050-U	CN-TX11 Series, Online transformer less double conversion UPS (single Phase In – single phase out), 10kVA/8kW, 0.8pf, 192Vdc, 6A charger without batteries

Features:

• Full digital control technology
• Three level inverter technology
• High AC/AC efficiency up to 94%
• Low THDi: < 5%
• High input power factor up to 0.996
• High output power factor up to 1.0
• Intelligent RS232+USB+EPO communication port
• ECO function
• Perfect LCD display panel
• Programmable rear panel
• 8A charger (optional)
• SNMP or dry contact (optional)

Applications:

• Point-of-sale
• Data centre
• Network device
• Commercial facility
• Precision instrument

Part No.	Description
77-1041- U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 1kVA/0.9kW, 0.9pf, 24Vdc, 1A charger with 2 x 12V, 9Ah batteries
77-1042-U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 1kVA/0.9kW, 0.9pf, 36Vdc, 4A charger without batteries
77-1043-U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 2kVA/1.8kW, 0.9pf, 48Vdc, 1A charger with 4 x 12V, 9Ah batteries
77-1044-U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 2kVA/1.8kW, 0.9pf, 72Vdc, 4A charger without batteries
77-1045-U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 3kVA/2.7kW, 0.9pf, 72Vdc, 1A charger with 6 x 12V, 7Ah batteries
77-1046-U	CN-TX11 plus Series, Online transformer less double conversion UPS (single Phase In – single phase out), 3kVA/2.7kW, 0.9pf, 96Vdc, 4A charger without batteries
